Jaw crushers are core crushing equipment in industries such as mining, construction, and metallurgy. The choice of model directly impacts production efficiency and operating costs. The PE600x900, a classic model for both secondary and coarse crushing, has garnered significant market attention. This article will comprehensively analyze this model's technical specifications, key advantages, and market price positioning, providing a reliable reference for your equipment selection.
I. Detailed Technical Parameters of the PE600x900 Jaw Crusher
The PE600x900 is a standard jaw crusher with the following technical specifications:
Basic Parameters:
• Feed opening dimensions: 600 x 900 mm
• Maximum feed size: 480 mm
• Discharge opening adjustment range: 65-160 mm
• Processing capacity: 90-180 t/h
• Spindle speed: 250 rpm
• Motor power: 55-75 kW (typically 75 kW)
Structural Parameters:
• Eccentric shaft speed: 250 rpm
• Main motor model: Y280M-6
• Weight: Approximately 15.5 tons (excluding motor)
• Overall dimensions (L x W x H): 2280 x 2370 x 1750 mm
Performance Features:
• High crushing ratio and uniform product size
• Deep-chamber crushing with zero dead zone design
• The shim-type discharge opening adjustment device is reliable and convenient.
II. Core Advantages of the PE600x900 Jaw Crusher
1. Rational Structure and Strong Durability
Made of high-quality steel, the movable jaw assembly undergoes precise calculations and processing to achieve higher strength and durability. The integral cast steel frame offers a stable structure and high compressive strength, adapting to various harsh working conditions.
2. High Crushing Efficiency and Stable Production Capacity
The 600×900mm feed opening allows for handling larger materials. The deep crushing chamber eliminates dead zones, increasing feed capacity and output. With a processing capacity of 90-180 tons/hour, it meets the needs of medium-sized production lines.
3. Easy Operation and Maintenance
The wedge-type adjustment system for the discharge opening is simple, safe, and quick. The rationally designed structure and easy replacement of wearing parts reduce downtime and maintenance, improving equipment utilization.
4. Low Energy Consumption and Economical Operation
The optimized crushing chamber improves crushing efficiency, producing higher output at the same power consumption, saving 15%-20% energy compared to traditional equipment, significantly reducing operating costs.
5. Wide Application
It can be used for coarse and secondary crushing of various ores and rocks with a compressive strength of up to 320 MPa, such as granite, marble, basalt, iron ore, limestone, and quartzite.
III. PE600x900 Jaw Crusher Price Analysis
The price of a PE600x900 jaw crusher is affected by a variety of factors, including:
1. Equipment Configuration Differences
Equipment configurations vary between manufacturers, and factors such as motor brand, bearing model, and plate thickness all affect the final price. High-quality domestic brands typically cost between 200,000 and 350,000 RMB, while imported or joint venture brands can cost as much as 400,000 to 600,000 RMB.
2. Market Factors
Steel price fluctuations, changes in market demand, and regional differences all influence equipment pricing. Furthermore, price adjustments may occur during different sales seasons.
3. Manufacturer's Craftsmanship
Well-known brand manufacturers offer superior craftsmanship, strict quality control, and comprehensive after-sales service, resulting in relatively higher prices but better value for money. Smaller manufacturers may offer lower quotes, but the quality and lifespan of their equipment may not be guaranteed.
4. Additional Costs
Equipment prices typically do not include shipping costs, installation and commissioning fees, taxes, and other fees. These additional costs account for approximately 10%-15% of the equipment price.
IV. Purchasing Recommendations
1. Clarify Your Needs: Select the appropriate model based on material hardness, feed and discharge particle size, and production capacity requirements.
2. Compare Multiple Manufacturers: Evaluate product quality, after-sales service, and pricing from different manufacturers.
3. On-site Inspection: If possible, visit the manufacturer's workshop or a customer's site to observe their use.
4. Focus on After-Sales Service: Choose a supplier with a comprehensive after-sales service network to ensure long-term, stable operation.
The PE600x900 jaw crusher, with its rational design, stable crushing performance, and economical operating costs, is an ideal choice for medium-sized crushing operations. While the initial investment is relatively high, its long-term operational efficiency and reliability will bring greater value to your business. When purchasing, we recommend considering equipment performance, manufacturer reputation, and after-sales service, rather than simply price, to ensure the best return on investment.
If you have specific material requirements or production capacity requirements, we recommend consulting a professional engineer for personalized selection advice to maximize the performance advantages of the PE600x900 jaw crusher.
