Mobile Impact Crusher
In the industrial mining and limestone primary crushing sector, traditional "fixed-structure" production lines are becoming an excessive asset burden. Baichy Heavy Industry's YDPZ series mobile impact crushing plant is specifically designed to resolve the conflict between high-output demands and complex site environments.
Why choose a mobile impact crusher?
Compared to traditional fixed production lines, the YDPZ mobile station highly integrates a jaw/impact crusher, feeder, vibrating screen, and belt conveyor into a single chassis. It can directly reach the front line of mine crushing, eliminating the long-distance transportation costs of limestone and enabling production within 24 hours of arrival. For medium-hardness materials like limestone, the impact crusher (PF series) provides excellent cubic finished particle shape, directly meeting the demands of the high-standard aggregate market.
Core Technological Advantages: Born for Hardcore Working Conditions
1. Reinforced Heavy-Duty Rotor:
The "heart" of the crusher. We employ a high-inertia, heavy-duty rotor, and through high-precision dynamic and static balance testing, ensure extremely high kinetic energy stability even at high speeds. This means that when processing large pieces of limestone, we can achieve a larger single-pass crushing ratio and lower energy consumption.
2. High-Chromium Plate Hammers Technology
For limestone and some hard rocks, YDPZ is equipped with specially formulated high-chromium wear-resistant plate hammers. Compared to ordinary manganese steel, their wear life is increased by 30%-50%, significantly reducing downtime losses caused by frequent replacement of wear parts.
3. Integrated Chassis and No Infrastructure Installation
No cement foundation construction or bolt pre-embedding is required. Once the equipment arrives on site, the hydraulic support system quickly deploys, and it is ready for operation. Whether in remote quarries or dynamically relocating construction waste disposal sites, it maintains extremely high flexibility.
Typical Technical Parameters (Taking YDPZ-PF Series as an Example)
| Parameter Name | Technical Specification (YDPZ-1010) | Technical Specification (YDPZ-1214) |
| Maximum Feed Size | ≤ 350 mm | ≤ 500 mm |
| Production Capacity | 50 - 100 t/h | 150 - 250 t/h |
| Crusher Model | PF-1010 | PF-1214 |
| Power Configuration | Diesel-Electric Dual-Power / Pure Electric | Diesel-Electric Dual-Power / Pure Electric |
| Transport Dimensions | 12.5m × 2.6m × 4.2m | 14.5m × 2.8m × 4.5m |
Note: Actual capacity depends on material hardness and feed-to-discharge ratio.
Frequently Asked Questions (FAQ)
Q1: What hardness level is a mobile impact crusher suitable for processing?
A: The ideal material to process is medium-hardness brittle materials such as limestone, gypsum, and dolomite (Mohs hardness below 5-6). For extremely hard granite or basalt, a combination of jaw crusher and cone crusher is recommended for better economic efficiency.
Q2: How to balance mobility and high output?
A: Baichy Heavy Industry integrates large-diameter impact crushers (such as the PF1315) into a foldable transport structure through a modular chassis design. This maximizes the production potential of mining operations while ensuring transportation compliance.
Q3: How to maintain the equipment?
A: The YDPZ series is equipped with a hydraulically opened casing system, which allows the crushing chamber to be fully opened in just a few minutes, making it extremely convenient to inspect or replace the hammers.
