Jaw Crusher Model List And Selection Guide

1. Complete list of jaw crusher models (PE/PEX series)

Note:

• PE series: suitable for coarse crushing, large feed particle size, high crushing ratio, suitable for mines, quarries and other scenes.

• PEX series: suitable for medium and fine crushing, with a more flexible adjustment range of the discharge port, suitable for construction waste treatment, sand and gravel aggregate production, etc.

2. Jaw crusher selection guide

2.1 Selection according to material characteristics

• High hardness materials (granite, basalt): It is recommended to use the PE series, such as PE-400×600, PE-500×750, to ensure the wear resistance and stability of the equipment.

​​• Medium and low hardness materials (limestone, shale): you can choose the PEX series, such as PEX-250×1000, to reduce energy consumption costs.

2.2 Select according to production capacity requirements

• Small production line (<50t/h): PE-250×400, PE-400×600 are recommended.

• Medium production line (50-150t/h): PE-500×750, PEX-300×1300 are recommended.

• Large production line (>150t/h): multiple jaw crushers or larger specifications are required, such as PE600×900, PE900×1200 and other models.

2.3 Select according to feeding and discharging requirements

• Large feed size (such as primary crushing of raw ore): select a model with a large feed port size (such as PE-500×750, PE-600×900).

​​• Discharging requirements are fine (such as building aggregates): choose the PEX series, the discharge port can be adjusted in a wider range.

2.4 Motor power and energy consumption optimization

• High production capacity needs to match high-power motors (such as PE-500×750 with 55kW motors), but the electricity cost needs to be considered.

• Users with high energy-saving requirements can choose variable frequency controlled jaw crushers to reduce no-load losses.

3. FAQs

Q1: What is the difference between PE and PEX jaw crushers?

• PE series: dedicated to coarse crushing, large feed port, high crushing ratio, suitable for hard rock crushing.

• PEX series: dedicated to medium and fine crushing, flexible discharge port adjustment, suitable for scenes with strict particle size requirements.

Q2: What is the general price of a jaw crusher?

• Small jaw crusher (PE-150×250) is about 50,000-100,000 yuan.

​​• Medium-sized jaw crusher (PE-400×600) is about 150,000-300,000 yuan.

​​• Large jaw crusher (PE-500×750 and above) is about 300,000-800,000 yuan.

​​Q3: How to extend the service life of the jaw crusher? ​​

​​• Regularly check the jaw plate, bearings, and lubrication system.

​​• Avoid overload operation and control the feed particle size.

​​• Choose high manganese steel jaw plate to improve wear resistance.

To choose the right jaw crusher model, you need to consider the material characteristics, production capacity requirements, discharge specifications and budget. If you need more accurate selection suggestions or customized solutions, please consult the Baichy Heavy Industry technical team, we will provide you with free selection guidance + the latest quotation!
