Sand Production Line Configuration Plan | Equipment List & Process Flow

Equipment configuration	Hopper, ZSW850x3000 vibrating feeder, PE500x750 jaw crusher, CS75 cone crusher, VSI7611 sand making mawww.baichychina.com/vsi7611-sand-making-machine.htmlchine, Vibrating screen, Sand recycling machine, Belt conveyor.
Raw materials	Limestone, Granite, Basalt, Quartz, River stone etc.
Feed Size	Less than 425mm
Finished product	Fine sand 0.25-0.35mm, medium sand 0.35-0.5mm, coarse sand 0.5mm.
Capacity	50-100t/h
Application	In sand quarry, mine, construction site, highway, road and bridge construction, concrete mixing station, water conservancy and hydropower, chemical industry and other industries.
Advantages	High production efficiency and low operating cost; Multi-functions and Flexible application; Good shape of finished sand and fineness is adjustable.

Production line related products

If you can't find other products, please contact customer service If you can't find other products, please contact customer service

Vibrating Feeder

We specialize in the production of vibrating feeders, used for uniform and continuous feeding in industries such as sand and gravel production lines, mineral processing, and building materials. The equipment has a large processing capacity, stable operation, and is compatible with various crushers.

Inquiry

PEX Fine Jaw Crusher

PEX fine jaw crusher is a fine crushing model of jaw crusher, mainly used for medium and fine crushing of medium-hard materials (such as granite, basalt, limestone, etc.), suitable for mining, building materials, metallurgy, chemical industry and other industries. Compared with PE coarse jaw crusher, PEX model has finer material (usually 0-20mm adjustable), suitable for secondary crushing or fine crushing process.

Inquiry

Trommel Screen

As a widely used screening equipment, the drum screen plays an important role in many fields due to its high efficiency, convenience, and environmental protection. The working principle is to control the sorting of materials based on the particle size.

Inquiry

50-100tph Sand making production line introduction:

PE500X750 jaw crusher:

• As the primary crushing equipment on the production line, it can break large stones or rocks into smaller particle sizes for further crushing or sand-making by subsequent equipment.

• PE500X750 means that its feed opening size is 500mm×750mm, which is suitable for medium-sized crushing operations.

CS75 cone crusher:

• Cone crushers are usually used in medium and fine crushing operations. They are capable of receiving materials from the jaw crusher and further crushing them to smaller particle sizes.

• CS75 may represent a certain model or specification of the cone crusher, suitable for use on a 50-100t/h production line.

3YK1548 vibrating screen:

• Vibrating screens are used to screen crushed materials and separate materials of different particle sizes to meet different production needs.

• 3YK1548 may indicate that the vibrating screen has 3 layers of mesh, with a size of 1500mm×4800mm, and is suitable for processing medium-sized materials.

VSI7611 sand-making machine:

• The sand-making machine is a key equipment on the production line. It can turn the crushed materials into sand that meets the requirements.

• VSI7611 may represent a certain model or specification of the sand-making machine, which is suitable for sand-making operations on a 50-100t/h production line.

50-100tph Sand making production line
