As global iron ore resources become increasingly scarce, the efficient utilization of low-grade iron ore has become an important topic in the mining industry. This article will systematically introduce the beneficiation technology, purification process and resource utilization plan of low-grade iron ore to help mining companies achieve cost reduction and efficiency improvement and enhance the economic value of lean iron ore.
1. What is low-grade iron ore?
Low-grade iron ore refers to iron ore resources with low iron content (usually less than 30%) and high impurity content. This type of ore has high direct smelting costs and low efficiency, and has traditionally been regarded as "lean ore" and abandoned. However, with technological advances, through efficient beneficiation and enrichment processes, low-grade iron ore can also become an important resource that can be economically developed.
Main characteristics of low-grade iron ore:
✔ Low iron content (Fe<30%)
✔ High impurity content (SiO₂, Al₂O₃, etc.)
✔ Fine mineral embedding particle size, difficult to separate
✔ Low recovery rate of traditional mineral processing, poor economic benefits
2. Key technologies for efficient utilization of low-grade iron ore
1.1 Physical mineral processing method (low cost, environmental protection)
• Magnetic separation method: Separation by magnetic difference of iron ore, suitable for magnetite, hematite, etc.
• Gravity separation method: Recover coarse iron ore by gravity separation (such as spiral chute, shaking table).
• Flotation method: Use specific reagents to make the bubbles attached to iron minerals float, suitable for fine-grained ore.
1.2 Chemical purification method (high recovery rate, but high cost)
• Acid leaching/alkali leaching method: Use sulfuric acid, hydrochloric acid or sodium hydroxide to dissolve impurities and improve iron grade.
• Reduction roasting-magnetic separation: convert weakly magnetic iron ore (such as hematite) into magnetite through high-temperature reduction, and then concentrate it through magnetic separation.
1.3 Biological leaching technology (green and environmentally friendly, future trend)
• Microbial leaching: use iron-oxidizing bacteria (such as acidthiobacillus) to selectively dissolve iron minerals, suitable for complex and difficult-to-select ores.
1.4 Combined process flow (improve comprehensive recovery rate)
• Magnetic separation-flotation combination: first magnetic separation to recover strong magnetic ore, then flotation to recover weak magnetic ore.
• Gravity separation-roasting combination: after coarse particles are concentrated through gravity separation, fine particles are roasted to strengthen separation.
3. Typical case analysis
Case 1: A low-grade hematite ore dressing plant
Ore grade: Fe 25%
Technology used: Strong magnetic separation → reverse flotation
Concentrate grade: Fe 65%, recovery rate 75%
Economic benefits: Profit per ton of ore increased by 40%
Case 2: Microbial leaching treatment of arsenic-containing iron ore
Ore problem: High arsenic (As>1%), difficult to handle by traditional methods
Solution: Bio-oxidation dearsenicization → magnetic separation enrichment
Result: Iron recovery rate>80%, arsenic content<0.1%
4. Economic benefits of low-grade iron ore utilization
• Single magnetic separation Low Low 50-70% Magnetite
• Magnetic separation-flotation Medium Medium 70-85% Mixed ore
• Roasting-magnetic separation High High 80-90% Hematite, limonite
• Biological leaching High 60-80% Complex and difficult to process
Key conclusions:
✔ Low-grade iron ore development requires personalized solution design
✔ Combined processes are usually more efficient than single methods
✔ Technological innovations (such as bioleaching) can break through traditional limitations
5. Future development trends
• Intelligent mineral processing: AI optimizes process flow and improves automation level
• Green and low-carbon technology: Reduce the use of chemical agents and reduce energy consumption
• Tailings resource utilization: Recover valuable elements from mineral processing waste
• Low-cost and high-efficiency reagents: Develop new flotation reagents to improve selectivity
The efficient utilization of low-grade iron ore can not only alleviate the shortage of iron ore resources, but also reduce mine waste and achieve sustainable development. With the advancement of mineral processing technology, the once abandoned "poor ore" is gradually becoming a new profit growth point.
